| Model Number |
MCB-B511D-KGNN-RGB |
|
|
|
| Materials |
Steel, Plastic, Tempered Glass |
|
| Dimensions (L x W x H) |
496 x 217 x 469 mm |
|
| Motherboard Support |
ATX, Micro ATX, Mini ITX |
|
|
|
| 2.5" / 3.5" Drive Bays (Combo) |
2 |
|
| 2.5" Drive Bays |
5 (Max.6) |
|
| I/O Panel |
2x USB 3.0, Audio In & Out (Supports HD Audio) |
|
| RGB Control |
RGB controller included, 1 to 3 RGB splitter cable included |
|
| Pre-installed Fans - Front |
3x 120mm RGB Fan |
|
| Pre-installed Fans - Rear |
1x 120mm |
|
| Fan Support - Top |
2x 120mm, 2x 140mm |
|
| Fan Support - Front |
3x 120mm, 2x 140mm |
|
| Fan Support - Rear |
1x 120mm |
|
| Radiator Support - Front |
120mm, 140mm, 240mm, 280mm, 360mm |
|
| Radiator Support - Top |
120mm, 240mm |
|
| Radiator Support - Rear |
120mm |
|
| Clearance - CPU Cooler |
165mm / 6.49" |
|
| Clearance - PSU |
180mm/7.1" |
|
| Clearance - GFX |
410mm/16.1" |
|
| Cable Routing - Behind Motherboard Tray |
19mm / 0.74" |
|
| Dust Filters |
Front, Top, Bottom |
|
| Power Supply Support |
Bottom Mount, ATX |
|
|
|
|
|
|
|
