Image Sensor
|
1/2.7" CMOS
|
|
Max. Resolution
|
2880 (H) × 1620 (V)
|
|
Min. Illumination
|
0.007 lux@F1.6 (Color, 30 IRE)
0.0007 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
Illumination Distance
|
Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light)
|
|
Illuminator Number
|
2 (Multi-core (IR + warm) light)
|
|
Angle Adjustment
|
Pan: 0° to 345°
Tilt: 0° to 90°
Rotation: 0° to 345°
|
|
Lens Type
|
Fixed-focal
|
|
Focal Length
|
4.0 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
H: 78°; V: 42°; D: 92°
|
|
Intelligence
|
|
Human Detection
|
Yes
|
|
Vehicle Detection
|
Yes
|
|
Audio and Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by sub stream)
|
|
Video Frame Rate
|
Main stream: 2880 × 1620@(1–25/30 fps)
sub stream: 640 × 360@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Video Bit Rate
|
H.264: 32 kbps–6144 kbps;
H.265: 32 kbps–6144 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
WDR
|
DWDR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Image Rotation
|
0°/180°
|
|
Built-in MIC
|
Yes, built-in Mic
|
|
Built-in Speaker
|
Yes, built-in speaker
|
|
Audio Compression
|
G.711a; G.711Mu; PCM
|
