Detection Range: 12m / 360°
SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
Fully remote configurable through App
Multiple enrollment method and easy installation design
Easy replaceable battery with PCB protected
Frequency hopping against jamming for reliable transmission
- Detection Performance
-
Detection MethodPassive Infrared
-
Detection Range12m
-
Detection Angle360°
-
Detection Zones172
-
Detectable Speed0.3～2m/s
-
SensitivityAuto;Low
-
White Light Filter6500lux
-
Digital Temperature CompensationSupport
-
Creep Zone ProtectionSupport
- Feature
-
Digital ProcessingSupport
-
Sealed OpticsSupport
-
Tamper ProtectionFront;Rear
-
Environment Temperature IndicatorSupport
-
Signal Strength IndicatorSupport
- Interface
-
Power SwitchPower Up Enrolling
-
LED IndicatorBlue(Alarm)
- Transmission
-
Transmission TechnologyTri-X Wireless
-
Transmission MethodTwo-Way RF Wireless
-
Transmission Frequency433MHz
-
Transmission SecurityAES-128 Encryption
-
Transmission Range(Free Space)1Km
-
Frequency HoppingSupport
-
Enrolling MethodPower up;Remote ID;QR Code
- Electrical Characteristics
-
Standard Battery LifeUp to 5 years (standby time)
-
Power SupplyBattery Powered
-
Battery TypeCR123A × 1
-
Typical Voltage3V
- General
-
Operation Temperature-10 °C to 55 °C (14 °F to 131 °F)
-
Storage Temperature-20 °C to 60 °C (-4 °F to 140 °F)
-
Operation Humidity10% to 90%
-
Dimension(WxHxD)φ101.2 mm x 32.9 mm
-
Weight109.5g
-
Mounting Height2.4 to 4m
-
Mounting MethodCeiling
-
Application ScenarioIndoor
